YD-022CS-LP
Tax Included – Shipping is calculated at checkout.
Keep ingredients fresh with our reliable 4-door upright chiller—ideal for restaurants and bakeries.
In stock
Share:
Pairs well with
Maximize your cold storage capacity and streamline your kitchen workflow with the YUDA Stainless Steel Upright 4 Doors Chiller. Designed for demanding commercial environments like bakeries, cafes, and catering operations, this 960-liter ventilated stand-up stainless steel chiller keeps your ingredients consistently fresh while optimizing your kitchen layout.
Built to Withstand Busy Kitchens
Crafted entirely from stainless steel, including the side panels and interior, this unit is engineered for hygiene, durability, and ease of cleaning—ideal for foodservice operations with strict cleanliness standards.
Powerful Cooling with Precision
Its ventilated cooling system ensures uniform temperature distribution (3°C to 8°C), which is crucial for maintaining food safety and prolonging ingredient shelf life. The digital controller on the front panel gives you precise temperature management at your fingertips.
Space-Saving, Easy Access Design
With four doors and three adjustable shelves, this upright chiller offers flexible storage. The stay-open door function allows for hands-free loading during busy prep times, and replaceable door gaskets ensure a tight seal over time.
Mobility Meets Stability
Heavy-duty castor wheels with locking brakes allow you to reposition the unit easily without compromising stability once in place—perfect for small to medium-sized commercial kitchens that need adaptable layouts.
Self-Evaporating & Auto Defrosting
Save time and maintenance effort. The self-evaporating system (optional) eliminates the need for drainage pipes, while automatic defrosting prevents ice buildup—keeping your chiller performing at its best without manual intervention.
| Specification | Details |
| Model | YD-022CS-LP |
| Product Type | Stainless Steel Upright Chiller |
| Manufacturer | KQF |
| Voltage | 240V |
| Frequency / Phase | 50Hz / Single Phase |
| Capacity | 960 Litres |
| Refrigerant | R134A |
| Temperature Range | 3°C to 8°C |
| Cooling System | Ventilated |
| Interior Material | Stainless Steel |
| Side Panel Material | Stainless Steel |
| Number of Shelves | 3 (adjustable) |
| Dimensions (WxDxH) | 1210 x 800 x 2040 mm |
| Weight | 160 kg |
| Evaporating System | Self-Evaporating (optional) |
| Defrosting | Automatic |
| Door Feature | Stay-open with replaceable seals |
| Mobility | Durable castor wheels with brakes |
| Plug Type | 13A |
| Insulation | Polyurethane, CFC-free |
1 Electrical wall socket(s) to be provided by customer within 1-meter from equipment, do not share equipment with heating equipment
| Dimensions | 1210.0 × 800.0 × 2040.0 cm |
|---|---|
| Specification | <ul><li><span style="font-family:Arial,Helvetica,sans-serif">Dimensions: W1210 x D800+50 x H2040 (mm)</span></li><li><span style="font-family:Arial,Helvetica,sans-serif">Capacity: 970 Litres</span></li><li><span style="font-family:Arial,Helvetica,sans-serif">Temperature: 2 to 8 <sup>o</sup>C</span></li><li><span style="font-family:Arial,Helvetica,sans-serif">Electrical: 220V/50Hz/1-Phase</span></li><li><span style="font-family:Arial,Helvetica,sans-serif">Socket: 13A</span></li></ul><table style="border-collapse:collapse; width:459pt; border:undefined" width="612" class=" cke_show_border"><tbody><tr height="17" style="height:12.5pt"><td class="xl65" height="17" style="width:99pt" width="132"><span style="font-family:Arial,Helvetica,sans-serif"></span></td><td class="xl66" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif"><b>YD-021CS-LP</b></span></td><td class="xl66" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif"><b>YD-022FS-LP</b></span></td><td class="xl66" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif"><b>YD-022CS-LP</b></span></td><td class="xl66" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif"><b>YD-022FS-LP</b></span></td><td class="xl66" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif"><b>YD-023CS-LP</b></span></td><td class="xl66" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif"><b>YD-023FS-LP</b></span></td></tr><tr><td class="xl65" height="17" style="width:99pt" width="132"><span style="font-family:Arial,Helvetica,sans-serif"><b>Type</b></span></td><td class="xl68" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">2-doors chiller</span></td><td class="xl68" style="width:120pt" width="160">2-doors freezer</td><td class="xl68" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">4-doors chiller</span></td><td class="xl68" style="width:120pt" width="160">4-doors freezer</td><td class="xl68" style="width:120pt" width="160">6-doors chiller</td><td class="xl68" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">6-doors freezer</span></td></tr><tr height="17" style="height:12.5pt"><td class="xl65" height="17" style="width:99pt" width="132"><span style="font-family:Arial,Helvetica,sans-serif"><strong style="height:12.5pt">Dimensions (mm)</strong></span></td><td class="xl68" colspan="2" rowspan="1" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">W760 X D800 +50 X H2040</span></td><td class="xl68" colspan="2" rowspan="1" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">W1210 X D800 +50 X H2040</span></td><td class="xl68" colspan="2" rowspan="1" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">W1818 X D800 +50 X H2040</span></td></tr><tr height="17" style="height:12.5pt"><td class="xl65" height="17" style="width:99pt" width="132"><span style="font-family:Arial,Helvetica,sans-serif"><strong style="height:12.5pt">Capacity (L)</strong></span></td><td class="xl68" colspan="2" rowspan="1" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">600</span></td><td class="xl68" colspan="2" rowspan="1" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">970</span></td><td class="xl68" colspan="2" rowspan="1" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">1480</span></td></tr><tr><td class="xl65" height="17" style="width:99pt" width="132"><span style="font-family:Arial,Helvetica,sans-serif"><strong>Temperature (<font class="font6"><font style="height:14.0pt"><sup>o</sup></font></font><font class="font5"><font style="height:14.0pt">C)</font></font></strong></span></td><td class="xl68" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">2 ~ 8</span></td><td class="xl68" style="width:120pt" width="160">-18 ~ -21</td><td class="xl68" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">2 ~ 8</span></td><td class="xl68" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">-18 ~ -21</span></td><td class="xl68" style="width:120pt" width="160">2 ~ 8</td><td class="xl68" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">-18 ~ -21</span></td></tr><tr><td class="xl65" height="17" style="width:99pt" width="132"><span style="font-family:Arial,Helvetica,sans-serif"><strong style="height:12.5pt">Electrical</strong></span></td><td class="xl68" colspan="2" rowspan="1" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">220/50Hz/1-phase</span></td><td class="xl68" colspan="2" rowspan="1" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">220/50Hz/1-phase</span></td><td class="xl68" colspan="2" rowspan="1" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">220/50Hz/1-phase</span></td></tr><tr><td class="xl65" height="17" style="width:99pt" width="132"><span style="font-family:Arial,Helvetica,sans-serif"><strong style="height:12.5pt">Plug<sup>1</sup></strong></span></td><td class="xl68" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">13A</span></td><td class="xl68" style="width:120pt" width="160">13A no sharing/ 15A</td><td class="xl68" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">13A</span></td><td class="xl68" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">15A or 20A isolator</span></td><td class="xl68" style="width:120pt" width="160">13A</td><td class="xl68" style="width:120pt" width="160"><span style="font-family:Arial,Helvetica,sans-serif">15A or 20A isolator</span></td></tr></tbody></table><p><span style="font-family:Arial,Helvetica,sans-serif"><sup>1 </sup>Electrical wall socket(s) to be provided by customer within 1-meter from equipment, do not share equipment with heating equipment</span></p> |
| Key Features | <ul><li>Blower system</li><li>Digital controller</li><li>Durable castor wheels</li><li>Stay-open doors for easy loading and removal of goods</li><li>Self-evaporation feature does not require drainage pipes (optional)</li><li>Automatic defrosting; no manual removal of ice required</li><li>Polyurethane thermal insulation CFC free</li></ul> |
| Description | <p>Commercial refrigerators (chillers) and freezers are essential for storing your fresh ingredients especially in cafes and bakery, catering operations.</p><p>Each unit is equipped with sturdy shelves to keep the items properly organized. Shelves are adjustable so you can adjust them to the height to fit your food cartons. </p><p>The doors come with a stay-open feature making it easier for reloading of goods. The digital controller is installed on the front allowing easier control and monitoring. Durable castor wheels with brakes allow easier manoeuvre.</p><p>Thanks to the self-evaporation feature (optional), you can do away unsightly water drain pipes or frequent emptying of drainage tray. </p> |
